IQ VISION

• 40’ x 40’ (12.2m x 12.2m) range
• 30lb pet immunity
• Advanced ASIC PIR technology
• Attractive two-tone bi-optic case
• Excellent EMI-/RMI-/lightning protection with resilient SMD circuitry
• Sealed sensor chamber prevents insect/draft interference
• Features look-down/creep zone
• SSP™ (Signal Selective Processing) for the easiest and most stable of installations
• Auto Temp compensation
• Advanced, EZ-Aim fresnel lenses for optimum detection performance
• Conventional wall or corner mounting
• Tamper supervised
• Form A relay (Form “C” option)
• Operating Temperature: 14°F to 122°F (-10°C to +50°C)
• Traditional Mounting: Wall or corner (hardware supplied)
• Alarm Output: Normally closed from A relay
• Contact Ratings: 100ma, 24VDC with internal 10 Ohm current-limiting resistor
• Power Supply Requirements: Unit is intended to operate from a power source that provides a 4 hr battery backup in the event of a power failure
• Filtered DC: 10.6 to 16 VDC with a battery back-up from control panel
• Current Drain: 16 mA @ 12 VDC nominal
• Dimensions: 4.5” x 2.5” x 1.8” (11.4 x 6.4 x 4.6cm) (H x W x D)
• Shipping Weight: 6 oz. (170.1g)
