CVC-6760- Color Scanning Bullet Camera

Our 1/4" color CCD indoor bullet scanning camera packages allow for large area coverage. The CVC-6760 has an adjustable automatic rotation range from 10° - 270°, complete with a stop/start remote control. With 350 line resolution and the ability to see in low light conditions of 1.0 lux F 1.4, the camera can be used for low light applications. It has a 2.9mm wide angle lens.This light weight camera unit includes a wall mount bracket, making for a quick and easy installation, and a 12V DC power supply. A B/W version of this camera can be found under model number CVC-1760, along with a ball version of the camera under model number CVC-5760. Technical Specifications Resolution 350 lines Minimum Illumination 1.0 lux F 1.4 Electronic Shutter auto 1/60 - 1/100,000 seconds Image Device 1/4" color CCD image device Number of Pixels 510 horizontal x 492 vertical Scanning System EIA standard 525 line 60 fields/second Lens 2.9mm wide angle lens Video Output Level 1.0 Vp-p 75 ohm Video S/N Ratio greater than 46 dB Operating Temperature 14 degrees F - 122 degrees F Humidity within 95 % RH Power Supply regulated 12V DC power supply (UL and CSA listed) Power Consumption 300 mA (TYPICAL), 78 degree diagonal Output Video- RCA with BNC adapter, power- DC jack Overall Dimensions 4"L x 1.5"W x 5.25"H Mount wall mount bracket included

CVC-1760- B/W Scanning Bullet Camera

Our indoor bullet scanning camera packages allow for large area coverage. The CVC-1760 has an adjustable automatic rotation range from 10° - 270°, complete with a stop/start remote control. With 420 line resolution and the ability to see in low light conditions of 0.02 lux F 1.4, the camera can be used for night applications. This light weight camera unit includes a wall mount bracket, making for a quick and easy installation, and a 12V DC power supply. A color version of this camera can be fond under model number CVC-6760, along with a ball version that can be found under CVC-3460. Technical Specifications Resolution 420 line Minimum Illumination 0.02 lux F 1.4 Electronic Shutter Speed Auto 1/60 - 1/100000 seconds Image Pick up Device 1/3" B/W CCD image sensor Number of Pixels 512 horizontal x 492 vertical Scanning System EIA standard 525 line 60 fields/second Lens 3.6mm wide angle, 78 degree diagonal Video Output Level 1.0 Vp-p 75 ohm Video S/N RAtio Greater than 46 dB Operating Temperature 14 degrees F- 122 degrees F Humidity Within 95 % RH Power Supply regulated 12V DC power supply (UL and CSA listed) Power Consumption 100 mA Base Dimensions 1 3/8" H x 2 3/8" Dia. Outputs Video-RCA with BNC adapter, power- DC jack Overall Dimensions 4"L x 1.5"W x 5.25"H Housing black Mount Wall mount bracket included Special Stop/start remote control included

CVC-5760- Color Scanning Mini-Ball Camera

Our 1/4" color CCD indoor ball scanning camera packages allow for large area coverage. The CVC-5760 has an adjustable automatic rotation range from 10° - 270°, complete with a stop/start remote control. With 350 line resolution and the ability to see in low light conditions of 1.0 lux F 1.4, the camera can be used for low light applications. It has a 2.9mm wide angle lens.This light weight camera unit includes a wall mount bracket, making for a quick and easy installation, and a 12V DC power supply. A B/W version of this camera can be found under model number CVC-3460, along with a bullet version that can be found under model number CVC-6760. Technical Specifications Resolution 350 lines Description ball camera Minimum Illumination 1.0 lux F 1.4 Electronic Shutter auto 1/60 - 1/100,000 seconds Image Device 1/4" color CCD image sensor Number of Pixels 510 horizotal x 492 vertical Video Output 1.0 Vp-p 75 ohm Operating Temperature 14 degrees F - 122 degrees F Lens 2.9mm wide angle Power Supply 12V regulated 12V DC power supply included (UL and CSA listed) Power Consumption 300 mA (TYPICAL) Overall Dimensions 3"L x 3"W x 6"H

CVC-3460- B/W Scanning Mini-Ball Camera

Our indoor ball scanning camera packages allow for large area coverage. The CVC-3460 has an adjustable automatic rotation range from 10° - 270°, complete with a stop/start remote control. With 420 line resolution and the ability to see in low light conditions of 0.02 lux F 1.4, the camera can be used for night applications. This light weight camera unit includes a wall mount bracket, making for a quick and easy installation, and a 12V DC power supply. A color version of this camera can be found under model number CVC-5760, along with a bullet version under model number CVC-1760. Technical Specifications Resolution 420 lines Minimum illumination 0.02 lux F 1.4 lens incandescent lighting Electonic Shutter auto 1/60 - 1/100,000 second Image Device 1/3" B/W CCD image sensor Number of Pixels 512 horizontal x 492 vertical Scanning System EIA standard 525 line 60 fields/second Lens 3.6mm wide angle lens Video Output Level 1.0 Vp-p 75 ohm Video S/N Ratio Greater than 46 dB Output Video - RCA with BNC adapter, power- DC jack Operating Temperature 14 degrees F - 122 degrees F Humidity Within 95 % RH Power Supply regulated 12V DC power supply included (UL and CSA listed) Power Consumption 300mA Housing black, adjustable automatic rotation range from 10 - 270 degrees Dimensions 3"L x 3"W x 6"H
