Click image to enlarge
Seco-Larm
3/8in Screw-Terminal Recessed-Mount Magnetic Contact

Model[SM-407-5TQ/W ]


3/4" (19mm) Gap, N.C., White

  • Used for protecting sliding doors and windows where space is limited.
  • Gold-plated terminals for longer life and reliability.
  • Screw terminals.
  • High-impact ABS plastic.
  • Miniature size assures ease of concealment.
  • Switch and magnet have ribs for securing in holes.
  • 3/8" Press-fit.
  • Contact reed switch is SPST, iridium-plated to have a high melting point and Vickers hardness, which results in higher handling power and long life.
  • For N.C. circuits.
  • 3/4" (19mm) Gap.
  • Lifetime limited warranty.
Circuit typeN.C.
Operation gap3/4", (19mm)
ColorWhite
MaterialCaseHigh-impact ABS plastic
ContactGold-plated
ContactsIridium-plated
Contact rating0.1A@100VDC (max)
1.0A@10VDC (max)
10W (max)
Temperature-68º~158º F (-20º~70º C)
Switch cycles50 Million (0.1mA@5VDC)
Switch dimensions1-1/8"x7/16"x3/8" (28x11x9mm)
Magnet dimensions3/4"x7/16"x3/8" (19x11x9mm)
MagnetRare-earth neodymium


Quantity:
